Serie 17

AVO – Wheel with thermoplastic polyurethane and aisi 304 stainless steel castor for industry, diameter 150mm ean 28741

32X

Material: Thermoplastic Polyurethane

Core: Polyamide 6

Application field: Industry

Request information

Description:

Wheel coated with injection-moulded red Polyurethane tread, 97 Shore A and Polyamide 6 centre. Hub on plain bore, roller bearing or shielded ball bearings assembled with central spacer.

Heavy-Duty Castors

Made of pressed stainless steel AISI 304, turning on double rim of stainless-steel balls AISI 420, with plate. Dust cover ring on the balls.

Product line: Polyurethane, Stainless steel

Linea di prodotto: Polyurethane, Stainless steel

EAN13: 8018793287418

EAN5: 28741

Article code: 06032X0150NRA

Features

-20 | 80

450

Stainless steel roller bearing

Shore A

97

Floor types

Concrete

Stoneware

Download pdf product sheet

download images

Request the drawing

Wheel data

Diameter (mm)

150

Band width (mm)

40

Hub width (mm)

60

Hub version

Stainless steel roller bearing

Wheel hole (mm)

20

Bearing seat (mm)

/

Dynamic load capacity (DaN)

450

Colour

Red

Material

Thermoplastic Polyurethane

Box pieces

/

Hardness scale

Shore A

Hardness

97

Bracket data

Plate size (mm)

135X110

Interaxis plate hole (mm)

105X080

Plate bore size (mm)

13X16

Offset (mm)

57

Height from ground (mm)

201

Castor hole (mm)

/

Static load capacity (DaN)

560

Structure

Swivel

Version

Plate

Brake

/

Pivot

/

Pivot type

/

Finishing

AISI 304 stainless steel
