Serie 116G

AVO – Wheel with 6 polyamide with aisi 304 stainless steelcastor for industry, diameter 80mm ean 18268

119FG

Material: 6 Polyamide

Core: Polyamide 6

Scope: Industry

Request information

Description:

Monolithic Polyamide 6 wheel. Hub on plain bore, roller bearings or shielded ball bearings assembled whit central spacer.

Medium duty castors

Made of pressed stainless steel AISI 304, turning on double rim of balls AISI 420, with bolt hole. Dust cover ring on the balls.

Product line: Polyamide, Stainless steel

EAN13: 8018793182683

EAN5: 18268

Article code: 06119F00800FG

Features

-25 | 85

150

Plain bore

Shore D

Flooring

Concrete

Stoneware

Download pdf product sheet

download images

Wheel data

Diameter (mm)

Band width (mm)

Hub width (mm)

Hub version

Plain bore

Wheel hole (mm)

Bearing seat (mm)

Dynamic load capacity (DaN)

150

Colour

Green

Material

6 Polyamide

Box pieces

Hardness scale

Shore D

Hardness

Castor data

Plate size (mm)

100X085

Interaxis plate hole (mm)

080X060

Plate bore size (mm)

8,5X12

Offset (mm)

Height from ground (mm)

105

Castor hole (mm)

Static load capacity (DaN)

190

Structure

Swivel

Version

Bolt hole

Brake

Pivot

Pivot type

Finishing

AISI 304 stainless steel
