Serie

AVO – Wheels with siliconica alta termperatura rubber tyre with castor steel for industry, diameter 100mm ean 20929

36-T

Material: Siliconica alta termperatura Rubber tyre
Core: Aluminum
Scope: Industry
Request information

Description:

Wheel with high-temperature silicone rubber tread 80 Shore A and aluminium wheel centre. Hub on shielded ball bearings.

Medium duty castors
Made of zinc-chromium plated pressed steel, turning on double rim of balls, with plate. Assembled with self-locking nut.
Product line: High temperature
EAN13: 8018793209298
EAN5: 20929
Article code: 1403600100TCA

Features

-40 | 280

120

Ball bearing
Shore A
80

Flooring

Asphalt
Concrete
Stoneware
Download pdf product sheet
36-T
36-T-3
36-T-4
36-T-5
36-T-7
36-T-8
download images

Wheel data

Diameter (mm)

100

Band width (mm)

40

Hub width (mm)

40

Hub version

Ball bearing

Wheel hole (mm)

15

Bearing seat (mm)

32X9

Dynamic load capacity (DaN)

120

Colour

Red

Material

Siliconica alta termperatura Rubber tyre

Box pieces

/

Hardness scale

Shore A

Hardness

80

Castor data

Plate size (mm)

100X085

Interaxis plate hole (mm)

080X060

Plate bore size (mm)

8,5X12

Offset (mm)

37

Height from ground (mm)

128

Castor hole (mm)

/

Static load capacity (DaN)

150

Structure

Swivel

Version

Plate

Brake

/

Pivot

/

Pivot type

/

Finishing

Galvanized
